Winner Pro + Online UPS switching power supply

Brand : Cassspower
Product origin : Shenzhen, China
Delivery time : 30 days
Supply capacity : 50K


Feature:

• True double-conversion

• Microprocessor control optimizes reliability

• Input power factor correction

• Output power factor 0.8/0.9

• Wide input voltage

• ECO mode for energy saving only available for 1-3KVA models

• Generator compatible

• Smart SNMP works well with either USB or RS-232 together

• Comprehensive display allows easy monitoring and access of UPS status

MODEL

W1KM/L

W2KM/L

W3KM/L

W6KM/L

W10KM/L

PHASE

Single phase with ground

CAPACITY *

1000 VA / 800 W

2000 VA / 1600 W

3000 VA / 2400 W

6000VA / 5400W

10000 VA / 9000 W

INPUT

Nominal Voltage

100/110/115/120/127VAC or 200/208/220/230/240VAC

208/220/230/240VAC

Input Voltage Range

55-150 VAC or 110-300 VAC (Based on load at 50%) 85-140VAC or 160-280VAC (Based on load at 100%)

110-300 VAC (Based on load at 50%) 176-300 VAC (Based on load at 100%)

Frequency Range

40 Hz ~ 70 Hz

46~54 Hz or 56~64 Hz

Power Factor

0.99 @ Nominall Voltage (100% load)

OUTPUT

Output Voltage

100/110/115/120/127VAC or 200/208/220/230/240VAC

208/220/230/240VAC

Voltage Regulation

± 1 %

Frequency Range (Synchronized Range)

47~ 53 Hz or 57 ~ 63 Hz

46~54 Hz or 56~64 Hz

Frequency Range (Batt. Mode)

50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz

50 Hz or 60Hz ± 0.1 Hz

Current Crest Ratio

3:1

Harmonic Distortion

3 % THD (Linear Load) 6 % THD (Non-linear Load)

3 % THD (Linear Load) 5 % THD (Non-linear Load)

Transfer Time

AC Mode to Battery Mode

Zero

Inverter to Bypass

4 ms (Typical)

Zero

Waveform (Batt. Mode)

Pure Sinewave

EFFICIENCY

AC Mode

88%

89%

90%

94%

94%

Battery Mode

83%

85%

88%

90%

91%

BATTERY

Standard Model

Battery Type

12 V / 9 Ah

12 V / 9 Ah

12 V / 9 Ah

12 V / 9 Ah

Numbers

2

4

6

16

16

20

Typical Recharge Time

4 hours recover to 90% capacity

9 hours recover to 90% capacity

Charging Current (max.)

1 A

1 A / 2 A

Charging Voltage

27.4VDC ± 1%

54.7 VDC ±1%

82.1 VDC ±1%

218.4 VDC ±1%

218VDC ±1%

273VDC ±1%

Long-run Model **

Battery Type

Depending on the capacity of external batteries

Numbers

2

4

6

16

16

INDICATORS

LCD

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

ALARM

Battery mode

Sounding every 4 second

Low Battery

Sounding every second

Overload

Sounding every 0.5 second

Fault

Continuously sounding

PHYSICAL

Standard

Model

Dimension, D X W X H (mm)

282 x 145 x 220

397 x 145 x 220

421 x 190 x 318

369 x 190 x 688

442 x 190 x 688

Net Weight (kgs)

9.8

17

27.6

61

66

76

Long-run

Model

Dimension, D X W X H (mm)

282 x 145 x 220

397 x 145 x 220

397 x 145 x 220

369 x 190 x 318

442 x 190 x 318

Net Weight (kgs)

4.1

6.8

7.4

12

16

ENVIRONMENT

Humidity

20-90 % RH @ 0- 40°C (Non-condensing)

0-95% RH @ 0-50°C(Non-condensing)

0-95% RH @ 0-40°C(Non-condensing)

Noise Level

Less than 50dBA @ 1 Meter

tLess than 55dBA @ 1 Meter

Less than 58dBA @ 1 Meter

MANAGEMENT

Smart RS-232 / USB

Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix, and MAC

Optional SNMP

Power management from SNMP manager and web browser

*1-3KVA: Derate to 80% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to 100/200/208VAC

6-10KVA: Derate to 60% of capacity in Frequency converter mode and to 90% when the output voltage is adjusted to 208VAC

**Long-run model is only available in 200/208/220/230/240VAC systems (200VAC system only available for 1-3KVA).

Product specifications are subject to change without further notice


Packaging and Transport :

Standard export carton. Each piece is packed by vacuum plastic bag into a inner box then 1pcs to a carton.

Delivery Detail: 5-15working days against payment.



Our Services:

1. Any inquiries will be replied within 24 hours;

2. Professional manufacturer , welcome to visit our website;

3. OEM/ODM available:

a) Print logo on our products

b) Customized specification

c) Customized color package box

d) Any your idea on our products,we can help you to design and put it into production

4. High qulity,fashion design,reasonable&competitive price,fast lead time

5. After-sale service:

a) All products will have been strictly quality checked in test house before packing

b) All products will be well packed before shipping

c) All products have 1-2 years warranty, and we sure the products will be free from maintenance within warranty period

6. Faster delivery:

Sample order in stock, and 3-7days for bulk production

7. Payment term:

L/C T/T open account transaction, westion union & paypal
