Compact 1U Online UPS switching power supply

Brand : Cassspower
Product origin : Shenzhen, China
Delivery time : 30 days
Supply capacity : 50K


Feature:

• True double-conversion

• Microprocessor control optimizes reliability

• Output power factor 0.8

• 1U compact size perfect fits for data processing

and transmission such as servers, networking and IP

telephone services

• Input power factor correction

• ECO mode for energy saving

• Built-in serial communication port/Dry contact

MODEL

1A 1K

1A 1K

CAPACITY

1000 VA / 800 W

1000 VA / 800 W

INPUT

Voltage

110/120 VAC or 220/230/240 VAC

220/230/240 VAC

Acceptable Voltage Range

55-150 VAC or 110-300 VAC @ 50% load 80-150 VAC or 160-300 VAC @ 100% load

110-300 VAC @ 50% load 160-300 VAC @ 100% load

Frequency Range

60/50 Hz (Auto sensing)

OUTPUT

Output Voltage

110/120 VAC or 220/230/240 VAC

220/230/240 VAC

Voltage Regulation

± 1%

Frequency Range

40-70 Hz (50/60Hz Auto sensing)

Frequency Range (Batt. Mode)

50/60 ± 0.5% Hz

Current Crest Ratio

5:1 (110/120 VAC) 3:1 (220/230/240 VAC)

3:1

Harmonic Distortion

3 % THD (Linear Load) 5 % THD (Non-linear Load)

Transfer Time

AC Mode to Battery Mode

0ms

Inverter to Bypass

4 ms (Typical)

Waveform (Batt. Mode)

Pure Sinewave

EFFICIENCY

AC Mode

88%

ECO Mode

92%

Battery Mode

85%

86%

BATTERY

Battery Type

Sealed Lead-acid battery

Lithium-iron battery or Sealed Lead-acid battery (Battery voltage: 48VDC)

Battery Spec & Numbers

6 V / 9 Ah x 4

Typical Recharge Time

4 hours recover to 90% capacity

Depending on external battery capacity

INDICATORS

LED

AC mode, Battery mode, and fault indicators

ALARM

Battery Mode

Sounding every 4 seconds

Low Battery

Sounding every second

Overload

Sounding twice every second

Fault

Continously sounding

PHYSICAL

Dimension, (D x W x Hmm)

477 x 438 x 44

300 x 440 x 44

Net Weight (kgs)

13

6

ENVIRONMENT

Humidity

20-90 % RH @ 0- 40°C (non-condensing)

Noise Level

Less than 50dBA @ 1 Meter

MANAGEMENT

USB or RS-232

Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and MAC

Dry Contact (Option)

Signal for AC Power Normal, Battery OK and Fault Alarm

Product specifications are subject to change without further notice.



Packaging and Transport :

Standard export carton. Each piece is packed by vacuum plastic bag into a inner box then 1pcs to a carton.

Delivery Detail: 5-15working days against payment.


Our Services:

1. Any inquiries will be replied within 24 hours;

2. Professional manufacturer , welcome to visit our website;

3. OEM/ODM available:

a) Print logo on our products

b) Customized specification

c) Customized color package box

d) Any your idea on our products,we can help you to design and put it into production

4. High qulity,fashion design,reasonable&competitive price,fast lead time

5. After-sale service:

a) All products will have been strictly quality checked in test house before packing

b) All products will be well packed before shipping

c) All products have 1-2 years warranty, and we sure the products will be free from maintenance within warranty period

6. Faster delivery:

Sample order in stock, and 3-7days for bulk production

7. Payment term:

L/C T/T open account transaction, westion union & paypal



Please feel free to give your inquiry in the form below. We will reply you in 24 hours.
